90QJD118 0.75kW 230V 5.4A 1", cable 25m

3.5" (90mm) suitable for narrow, deep holes.

Multi-purpose submersible pump, multistage type with floating impeller. Suitable for wells with a diameter of 3.5" and more. Designed for pumping clean and potable water for irrigation and water supply in households and industry.

SKU : JD212.00021

Vendor : JIADI

Specifications

Max head [m] 101

Max flow [l/min] 47

Recommended head H [m] 76

Recommended flow Q [l/min] 25

Voltage [V] 230

Motor power P2 [kW] 0.75

Max current [A] 5.4

Pump diameter (mm) 90

Max submersion depth (m) 30

Discharge connection ["] 1

Dĺžka kábla [m] 25

Impeller material Noryl

Check valve Zabudovaná

Max sand resistance (g/m3) 100

Capacitor box Ano

Motor speed control Suitable

Integrated pressure unit No

Dry-run protection No

Max medium temperature [°C] 35

Thermal protection built-in

IP rating 68

Pressure switch [MPa] No

Pressure tank [l] No

Warranty (months) 24

Vrátane DPH

In stock
